参数资料
| 型号： | PC2SD11NXPAF |
| 厂商： | Sharp Microelectronics |
| 文件页数： | 12/15页 |
| 文件大小： | 0K |
| 描述： | PHOTOCOUPLER TRIAC OUT 6-SMD |
| 产品目录绘图： | PC Series Circuit |
| 标准包装： | 1 |
| 电压 - 隔离： | 5000Vrms |
| 通道数： | 1 |
| 电压 - 断路： | 400V |
| 输出类型： | 交流标准三端双向可控硅开关 |
| 电流 - 栅极触发电流 (Igt)（最大）： | 10mA |
| 电流 - 保持 (Ih)： | 100µA |
| 电流 - DC 正向(If)： | 50mA |
| 电流 - 输出 / 通道： | 100mA |
| 安装类型： | 表面贴装 |
| 封装/外壳： | 6-SMD |
| 供应商设备封装： | 6-SMD |
| 包装： | 标准包装 |
| 产品目录页面： | 2768 (CN2011-ZH PDF) |
| 其它名称： | 425-2573-6 |
520
PC2SD11NTZ Series
■ Package specification
● Sleeve package
1. Through-Hole or SMT Gullwing
Package materials
Sleeve : HIPS (with anti-static material)
Stopper : Styrene-Elastomer
Package method
MAX. 50pcs of products shall be packaged in a sleeve.
Both ends shall be closed by tabbed and tabless stoppers.
The product shall be arranged in the sleeve with its anode mark on the tabless stopper side.
MAX. 20 sleeves in one case.
Sleeve outline dimensions
12.0
± 2
520
6.7
2. Wide Through-Hole or Wide SMT Gullwing
Package materials
Sleeve : HIPS (with anti-static material)
Stopper : Styrene-Elastomer
Package method
MAX. 50pcs of products shall be packaged in a sleeve.
Both ends shall be closed by tabbed and tabless stoppers.
The product shall be arranged in the sleeve with its anode mark on the tabless stopper side.
MAX. 20 sleeves in one case.
Sleeve outline dimensions
15.0
± 2
6.35
(Unit : mm)
(Unit : mm)
Sheet No.: D2-A07401EN
12
